Features

Maximum working pressure:

Stainless steel: 6000 psig (414 bar)

Alloy400: 5000psig (345bar)

Working temperature:

Acetal:-20°F to 250°F (-28℃ to 121 ℃)

PEEK:-20°F to 400°F (-28℃ to 204℃)

PFA:-20°F to 400°F (-28℃ to 204℃)

Nonrotating stem for longer seat life

Roddable, straight through flow path for maximum flow with minimum pressure drop

Stem thread lubricant isolated from system media

Replaceable seat and stem tip design

Stem thread protected from outside contamination by PTFE ring in the gland

Panel mounting available as an option

Steady and durable fastening of the handle by double lock-pins

Handle of different colors available for option

Leak-tight performance testing for every valve with nitrogen at the maximum working pressure
