Connection types:

AF3 type (bottom mount)

AF5 type (center mount with front flange)

L-AF3 type (bottom mount)

L-AF5 type (center mount with front flange)

Optional: with light, easy to read at night

Application:

cooling system, portable manifolds

Specification

Size:  2.5”(63mm)

Measuring Range: compound ranging with temperature and pressure vacuum 76cmHg (30″Hg) up to 500 psi (35 bar)

Dial: white aluminum with markings and graduations

Window: threaded polycarbonate

Pointer: black finished aluminum

Ring: black (red, blue) painted steel, 304 stainless steel

Case: black (red, blue) painted steel, 304 stainless steel

Movement: brass

Socket: brass

Bourdon Tube: phosphor bronze C-tube

Connection: 1/8″, 1/4″, 3/8″PT, NPT, BSP, 7/16″UNF thread

Mounting: bottom, center back with flush mount

Accuracy: +/-1.5% of full scale

Operating Temperature Limit: -20 ~ 60°C (-4 ~ 140°F)
