Size:  2-1/2″ (60mm)

Measuring range: -760mmHg vacuum to 1,000kg/cm2 (MPa, bar, kPa, psi)

Case: BLUE ABS

Socket: brass

Digits: 4-digits / backlighting

Connection: 1/4″, 1/2″ PT (per request)

Mounting: bottom

Accuracy: +/- 0.4% of BFSL

Response time: ≦ 50ms

Overpressure: 150%

Power supply: 2 x 1.5v AA or AAA cell

Humidity: ≦ 80 %

Medium Temperature: -20 ~ 80°C

Ambient Temperature: -10 ~ 50°C
