Size: NPS 1/2″- 12″

Pressure Ratin : Class 150Lb-800L

Material: LC8,LCC,CF8,CF8M,LC3,LF2,LF3,F304,F316

Design & Manufacturing Standard: BS 1873,ASME B16.34,API 602 BS5352

Face to Face: ASME B16.5 EN558(Threaded and sw as per manufacturer std)

Flanged Dinlension: ASME B16.5,(BSEN 1092)

Butt Weld Dinlension: ASME B16.25

Threaded end Dimension: ASME B1.20.1

Socketweld Dinlension: ASME B16.11

Pressure Tenlperature: ASME B16.34

Test and Inspection: API 598,BS 6364

Operation Methed:Manual,Worm Gear,Electric Actuator,Pneumatic Actuator,Hydraulic Actuator
